The tarm 2.5 show laser projector is a full color whitelight RGB laser systems with full analog color modulation and diode-only equipment. The guaranteed output power is specified at 2'700 mW after optics.
The tarm 2.5 (ShowNET) comes with integrated ShowNET network interface and free laser show software. Details in the box below.
The benefits include:
The tarm two laser has great beam specifications with a diameter of ca. 3.5 mm and a beam divergence of approx. 0.9 mrad (full angle).
It is equipped with a bright red (750 mW / 638 nm), a green (700 mW / 520 nm), and a blue (1'500 mW / 450 nm) diode laser source.
The scanners are very fast with 45 kpps@8° ILDA standard and allow for a maximum scan angle of 45° (@30 kpps). Thus they are well graphics capable and suitable for professional laser applications.
Optionally as upgrade available: CT-6210H scanners incl. LAS Turboscan driver with 60 kpps@8° ILDA and a max. scan angle of 60° (@35 kpps).
This show laser light has a switchable scan safety and switches for x-axis and y-axis flip. Color intensity can be adjusted with trim pots per color channel.
The housing of the tarm 2.5 is built very rugged and in a dust-proof way, so there is no air circulation inside the enclosure. This reduces maintenance efforts to a minimum.
The mounting bracket allows for hanging and for upright mounting of the laser system.
The tarm 2.5 is especially suitable for show laser applications in clubs and bars and can be used by beginners as well as professionals.
+ Integrated ShowNET incl. free laser show software
The tarm 2.5 features an integrated ShowNET network interface with free laser control software included!
Start with your own professional laser show thanks to the intuitive Showeditor laser show software which comes with every new tarm 2.5 (ShowNET) for free. The Showcontroller software is supported as well and can be purchased additionally.
The integrated ShowNET allows for direct input through ILDA and LAN. Besides DMX, it is possible to trigger single frames via ArtNet. You can play custom frames and shows from an integrated SD card (included in delivery) – even in stand-alone mode!
There are two different DMX modes:
(1) DJ Mode with the most used features for beginners. Only a few DMX channels are used for a quick and easy access to the most important adjustments directly at the laser system.
(2) Professional Mode with all DMX features especially for users with a DMX console. All adjustments can be triggered and allow for full control of the professional laser show.
The integrated ShowNET works as DAC (digital to analog converter) and enables ILDA streaming.
|Scanning system:||45 kpps @ 8° ILDA /scan angle max 45°/30kpps/|
|Beam Specifications (full angle):||ca. 3.5 mm / 0.9 mrad|
|Power Consumption:||100 W|
|Dimensions / L x W x H /:||220x220x150 mm|
|Accessories:||power cable, manual, key, interlock connector|
